System.Threading.RateLimiting 9.0.0

Prefix Reserved
dotnet add package System.Threading.RateLimiting --version 9.0.0
NuGet\Install-Package System.Threading.RateLimiting -Version 9.0.0
This command is intended to be used within the Package Manager Console in Visual Studio, as it uses the NuGet module's version of Install-Package.
<PackageReference Include="System.Threading.RateLimiting" Version="9.0.0" />
For projects that support PackageReference, copy this XML node into the project file to reference the package.
paket add System.Threading.RateLimiting --version 9.0.0
#r "nuget: System.Threading.RateLimiting, 9.0.0"
#r directive can be used in F# Interactive and Polyglot Notebooks. Copy this into the interactive tool or source code of the script to reference the package.
// Install System.Threading.RateLimiting as a Cake Addin
#addin nuget:?package=System.Threading.RateLimiting&version=9.0.0

// Install System.Threading.RateLimiting as a Cake Tool
#tool nuget:?package=System.Threading.RateLimiting&version=9.0.0

About

Provides a set of types that enable application developers to control the rate of operations. This can be used to ensure that applications do not exceed certain limits when interacting with resources or services.

Key Features

  • Flexible rate-limiting primitives that can be applied to various scenarios.
  • Supports token bucket, fixed window, and sliding window strategies.

How to Use

This is an example of an HttpClient that does client side rate limiting.

Define a rate limiter.

internal sealed class ClientSideRateLimitedHandler : DelegatingHandler, IAsyncDisposable
{
    private readonly RateLimiter _rateLimiter;

    public ClientSideRateLimitedHandler(RateLimiter limiter)
        : base(new HttpClientHandler())
    {
        _rateLimiter = limiter;
    }

    // Override the SendAsync method to apply rate limiting.
    protected override async Task<HttpResponseMessage> SendAsync(HttpRequestMessage request, CancellationToken cancellationToken)
    {
        // Try to acquire a token from the rate limiter.
        using RateLimitLease lease = await _rateLimiter.AcquireAsync(permitCount: 1, cancellationToken);

        // If a token is acquired, proceed with sending the request.
        if (lease.IsAcquired)
        {
            return await base.SendAsync(request, cancellationToken);
        }

        // If no token could be acquired, simulate a 429 Too Many Requests response.
        var response = new HttpResponseMessage(HttpStatusCode.TooManyRequests);

        // Add a 'Retry-After' header if the rate limiter provides a retry delay.
        if (lease.TryGetMetadata(MetadataName.RetryAfter, out TimeSpan retryAfter))
        {
            response.Headers.Add("Retry-After", ((int)retryAfter.TotalSeconds).ToString(NumberFormatInfo.InvariantInfo));
        }

        return response;
    }

    // Implement IAsyncDisposable to allow for asynchronous cleanup of resources.
    public async ValueTask DisposeAsync()
    {
        // Dispose of the rate limiter asynchronously.
        await _rateLimiter.DisposeAsync().ConfigureAwait(false);

        // Call the base Dispose method.
        Dispose(disposing: false);

        // Suppress finalization.
        GC.SuppressFinalize(this);
    }

    // Dispose pattern to clean up the rate limiter.
    protected override void Dispose(bool disposing)
    {
        base.Dispose(disposing);

        if (disposing)
        {
            // Synchronously dispose of the rate limiter if disposing is true.
            _rateLimiter.Dispose();
        }
    }
}

Using the rate limiter.

using System.Globalization;
using System.Net;
using System.Threading.RateLimiting;

// Initialize the rate limiter options.
// TokenLimit: Maximum number of tokens that can be acquired at once.
// QueueProcessingOrder: The order in which queued requests will be processed.
// QueueLimit: Maximum number of queued requests.
// ReplenishmentPeriod: How often tokens are replenished.
// TokensPerPeriod: Number of tokens added each period.
// AutoReplenishment: If true, tokens are replenished automatically in the background.
var options = new TokenBucketRateLimiterOptions
{
    TokenLimit = 4,
    QueueProcessingOrder = QueueProcessingOrder.OldestFirst,
    QueueLimit = 2,
    ReplenishmentPeriod = TimeSpan.FromMilliseconds(1),
    TokensPerPeriod = 2,
    AutoReplenishment = true
};

// Create a new instance of the TokenBucketRateLimiter with the defined options.
TokenBucketRateLimiter tokenBucketRateLimiter = new TokenBucketRateLimiter(options);

// A custom HttpMessageHandler that limits the rate of outgoing HTTP requests.
ClientSideRateLimitedHandler clientsideRateLimitedHandler = new ClientSideRateLimitedHandler(tokenBucketRateLimiter);

// Create an HttpClient that uses the rate-limited handler.
using HttpClient client = new HttpClient(clientsideRateLimitedHandler);

// Generate a list of dummy URLs for testing the rate limiter.
var oneHundredUrls = Enumerable.Range(0, 100).Select(i => $"https://example.com?iteration={i:00}");

// Issue concurrent HTTP GET requests using the HttpClient.
// The rate limiter will control how many requests are sent based on the defined limits.
await Parallel.ForEachAsync(oneHundredUrls.Take(0..100), async (url, cancellationToken) =>
{
    using HttpResponseMessage response = await client.GetAsync(url, cancellationToken);
    Console.WriteLine($"URL: {url}, HTTP status code: {response.StatusCode} ({(int)response.StatusCode})");
});

Main Types

The main types provided by this library are:

  • System.Threading.RateLimiting.RateLimiter
  • System.Threading.RateLimiting.ConcurrencyLimiter
  • System.Threading.RateLimiting.FixedWindowRateLimiter
  • System.Threading.RateLimiting.ReplenishingRateLimiter
  • System.Threading.RateLimiting.SlidingWindowRateLimiter
  • System.Threading.RateLimiting.TokenBucketRateLimiter
  • System.Threading.RateLimiting.PartitionedRateLimiter<TResource>

Additional Documentation

Feedback & Contributing

System.Threading.RateLimiting is released as open source under the MIT license. Bug reports and contributions are welcome at the GitHub repository.
